NUROIL / BITUMEN / NATURAL (GILSONITE)

Gilsonite.Natural bitumen.

A naturally occurring solid hydrocarbon used as a performance additive in ink, paint, foundry sand, drilling fluid and asphalt modification, not as a primary paving binder.

Natural bitumenLump · powder
OriginNatural asphaltitemined, not refined
FormLump · screened powderto an agreed mesh size
Softening point180 – 205 °Ctypical, ASTM D36
QualityBatch CoAon every shipment
01 / YOUR SUPPLY PARTNER

Why source
gilsonite from Nuroil.

Grade, specification and delivery confirmed for your requirement, from Nuroil Trading in Sharjah.

  • Pencil sketch of glossy black gilsonite lumps with conchoidal fracture faces beside a tray of dark brown ground powder, a sieve and a spatula

    Lump or screened powder

    Irregular lump for buyers with crushing facilities, or screened powder with a controlled mesh size for direct formulation use.

  • Pencil sketch of a technical data sheet, certificate of analysis and bitumen sample tins

    Batch Certificate of Analysis

    Each batch is supplied with a Certificate of Analysis for the properties critical to your application.

  • Pencil sketch of Gilsonite bags loaded in a shipping container

    Containerised supply

    Packing and loading are planned around your volume and destination, in bulk bags or powder bags.

02 / THE MATERIAL

What is
natural gilsonite?

IN SHORT

Gilsonite is a hard, brittle, glossy black-to-dark-brown asphaltite formed naturally underground over geological time. Unlike every petroleum-derived binder family, it is extracted by mining.

Pencil sketch of glossy black gilsonite lumps with conchoidal fracture faces beside a tray of dark brown ground powder, a sieve and a spatula
Material
Natural asphaltite
Origin
Uinta Basin, Utah, USA
Form
Lump or screened powder
Softening point
180 – 205 °C
03 / READING THE GRADES

Reading the
specification.

Typical commercial values. They vary meaningfully by deposit and grade; confirm the specific batch Certificate of Analysis.

  1. 01

    Softening point 180 – 205 °C

    Ring and ball, ASTM D36: far higher than conventional paving bitumen, with penetration 0.0 (0.1 mm) at 25 °C.

  2. 02

    Ash 2.0 – 10.0% wt

    ASTM D3174: commercial grades are valued for controlled mineral content.

  3. 03

    Solubility in CS₂ 81.0% wt

    ASTM D4, with normal heptane insolubles of 79.0% wt (ASTM D3279).

  4. 04

    Lump or screened powder

    Form by visual and sieve analysis; powder is classified to the agreed mesh range.

04 / STRENGTHS & LIMITS

Strengths and limits
of natural bitumen.

What it tells you

  • Thermal performance: a high softening point supports heat-resistant formulations.
  • Strong colour: deep black pigmentation suits ink, paint and coatings.
  • Binder enhancement: it can improve hardness, adhesion and resistance in compatible systems.
  • Flexible sizing: lump or controlled powder mesh supports different production routes.

What it does not tell you

  • It is not a standalone paving binder: its high softening point and brittleness suit it to blending with petroleum bitumen.
  • It is not universally compatible: it is soluble in aromatic solvents, so confirm the solvent system.
  • Properties are not fixed: they vary by deposit and grade, so check the batch CoA against the formulation.
  • The dosage is not set by the specification: validate addition rate, dispersion and performance at formulation scale.
05 / FULL COMPARISON

Catalogue
specifications.

Typical commercial values, with the elemental analysis. Values vary meaningfully by deposit and grade; the batch Certificate of Analysis decides.

Technical data sheet · Typical values

Natural bitumen (Gilsonite)

NUR-BT-GILNatural asphaltite · lump or powder
Ash content
2.0 – 10.0% wtASTM D3174
Moisture content
1.0 – 3.0% wtASTM D3173
Volatile matter
63.0% wtASTM D3175
Fixed carbon
29.0% wtASTM D3172
Solubility in CS₂
81.0% wtASTM D4
Specific gravity at 25 °C
1.01 – 1.06ASTM D3289
Normal heptane insolubles
79.0% wtASTM D3279
Colour in mass
Black
Colour in streak or powder
Brown
Softening point
180 – 205 °CASTM D36
Penetration at 25 °C
0.0 (0.1 mm)ASTM D5
Form
Lump or screened powderVisual / sieve analysis
Carbon
74.0% wtASTM D5291
Hydrogen
9.1% wtASTM D5291
Nitrogen
1.67% wtASTM D5291
Oxygen
3.1% wtASTM D5291
Sulphur
0.5% wtLeco (S) analyser

Typical commercial values; they vary by deposit and grade. The Certificate of Analysis for the offered batch decides.

Issued for every batchRequest the Certificate of Analysis
06 / SELECTION

Choosing the form
for your process.

Share the target application and critical properties so the supply can be matched to your process.

  1. 01
    Requirement

    Crushing facilities on site

    Lump in bulk bags

    Irregular material for buyers with crushing facilities.

  2. 02
    Requirement

    Direct formulation use

    Screened powder

    Controlled mesh size for direct formulation use.

  3. 03
    Requirement

    Ink, paint and coatings

    Gilsonite as an additive

    Deep colour, gloss and hardness for black ink, paint and coating formulations.

  4. 04
    Requirement

    Asphalt modification

    Blended into petroleum bitumen

    Increases high-temperature stiffness.

07 / APPLICATIONS

Made for the work
your operation does.

Match the product to the crop, equipment or process and confirm the specification before you order.

Pencil sketch of black ink, a paintbrush and Gilsonite lumps01

Ink and paint

Deep colour, gloss and hardness for black ink, paint and coating formulations.

Pencil sketch of a foundry mould, molten metal and Gilsonite lumps02

Foundry sand

Carbonaceous additive supporting mould release and casting-surface quality.

Pencil sketch of a drilling rig, fluid vessel and Gilsonite lumps03

Drilling fluid

Fluid-loss and borehole-stability additive in compatible oilfield formulations.

Pencil sketch of asphalt layers, a roller and Gilsonite lumps04

Asphalt modification

Blended into petroleum bitumen to increase high-temperature stiffness.

Pencil sketch of a tyre, industrial mixing vessel and Gilsonite lumps05

Rubber and plastics

Performance filler or modifier in selected compound systems.

08 / HOW IT IS MADE

Where gilsonite
comes from.

Ancient hydrocarbon-rich material migrated through sedimentary rock and solidified within narrow, near-vertical veins. Mining follows those veins before the material is sorted, crushed and screened.

Gilsonite oreVein seamBaggingLump · powder01Natural deposit02Mine03Sort and crush04Screen
  1. 01

    Natural deposit

    Asphaltite solidifies in underground rock veins.

  2. 02

    Mine

    The solid material is mechanically extracted.

  3. 03

    Sort and crush

    Lumps are cleaned and reduced to the required size.

  4. 04

    Screen

    Powder is classified to the agreed mesh range.

09 / COMPATIBILITY & HANDLING

Prepare the
formulation.

Confirm the solvent system, dust controls and dosage for your process before the shipment arrives.

  1. 01

    Confirm solvent system

    Gilsonite is soluble in aromatic solvents but not universally compatible.

  2. 02

    Control dust

    Powder handling requires suitable extraction and respiratory precautions.

  3. 03

    Trial the dosage

    Validate addition rate, dispersion and performance at formulation scale.

  4. 04

    Protect from moisture

    Store bags closed and dry to preserve consistent feeding.

10 / REFERENCE METHODS

Quality and
test methods.

Batch results for softening point, ash, moisture and other agreed properties are reported on the Certificate of Analysis.

01
ASTM D3174 / D3173
Ash and moisture content
02
ASTM D3175 / D3172
Volatile matter and fixed carbon
03
ASTM D4 / D3279
Solubility in CS₂ and normal heptane insolubles
04
ASTM D36 / D5
Softening point and penetration
05
ASTM D3289 / D5291
Specific gravity and elemental analysis
06
Mesh confirmation
Sieve range confirmed for screened powder orders
11 / PACKING & DELIVERY

Packing
formats.

Availability depends on the product, quantity and receiving facilities. Confirm the arrangement for your order.

  • 1,000kg
    01 / IRREGULAR LUMP

    Lump in bulk bags

    Irregular material for buyers with crushing facilities.

    Discuss this format
  • 25 kg
    02 / AGREED MESH SIZE

    Screened powder bags

    Controlled mesh size for direct formulation use.

    Discuss this format
  • 03 / BULK BAGS · POWDER BAGS

    Containerised supply

    Packing and loading planned around volume and destination.

    Discuss this format
13 / PRICE ON THE DAY

Get today’s price.

Prices follow the market, so we quote each order on the day. Share your product, quantity and delivery point and we send a firm offer within 24 hours.

Request today’s price
14 / BUYING THIS RANGE

Frequently asked questions.

Product, documentation, delivery and terms for this range.

Question not listed?

Share your grade, destination and packing and we will answer with the offer.

Discuss your requirement ↗
01Is Gilsonite the same as regular bitumen?
No. Gilsonite is naturally occurring asphaltite mined from underground deposits, not refined from crude oil. It is primarily an additive rather than a standalone paving binder.
02Where does Gilsonite come from?
It occurs in natural asphaltite veins in sedimentary rock; significant commercial deposits are associated with the Uinta Basin in Utah, USA.
03Can Gilsonite be used for paving on its own?
Not typically. Its high softening point and brittleness make it better suited as an additive to conventional petroleum bitumen.
04What industries use Gilsonite?
Ink and paint, foundry, oil and gas drilling fluid, asphalt modification, and rubber or plastics processing.
05What forms are supplied?
Irregular lump for on-site crushing and screened powder produced to an agreed mesh size.
06What documents come with each shipment?
Every shipment includes a Certificate of Analysis. Certificate of Origin and MSDS are available on request.
07What Incoterms do you offer?
FOB is commonly quoted from UAE ports; CFR and CIF destination-port offers are available.
08Does the softening point vary between batches?
Properties vary by source deposit and grade, so the batch Certificate of Analysis should always be checked against the formulation.
